    Telescopic Diesel Gasoline Dual Fuel 16ton Forklift Standard Emission Hydraulic Hand Pallet 14.5 Meter Forklift

    Ask Lasest Price
    Brand Name : HNTC180
    Model Number : HNTC160
    Certification : CE
    Price : USD20500-25500 / PIECE
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 500PIECE/ MONTH
    Delivery Time : 10-25 DAY
    • Product Details
    • Company Profile

    Telescopic Diesel Gasoline Dual Fuel 16ton Forklift Standard Emission Hydraulic Hand Pallet 14.5 Meter Forklift

    Telescopic Diesel Gasoline Dual Fuel 16ton Forklift Standard Emission Hydraulic Hand Pallet 14.5 Meter Forklift


    Product Description


    The panoramic cab and the visual identity appearance design feature good fashion and elegance.

    With compact short wheelbase and lateral engine arrangement, this machine features high handinessand flexibility.

    The integrated static-pressure stepless variable drive system realizes full speed range drive and stable driving.

    The four-wheel drive and multiple steering modes (including four-wheel, two-wheel, and crab steering modes) realize super-strong off-road capability and adapt to diversified working conditions.


    The inching control technology and special overload control system are applied to achieve high operation safety and reliability.

    The electro-hydraulic proportional control for the working system features accurate, stable, and efficient operations.

    The advanced human-machine interactivity, intelligent heat dissipation system, and dedusting control system embody high technologic sense and intelligence.

    This machine can be equipped with diversified attachments, including aerial platform, bucket, and bale clamp, to meet the users’ individual needs.


    Basic
    parameter
    Max. Lifting height (with out trigger)
    15M
    Rated load capacity (lifting)
    4000KG
    Max. Horizontal reach
    10.5M
    Rated load @ Max. Horizontal reach (with outrigger)
    800KG
    Load center
    500MM
    Operating weight (unloaded with fork)
    16000KG
    Max. Travailing speed (km/hour)
    28KM/H
    Swinging speed
    3 rpm(1500rpm)
    Transmission
    system
    Transmission type
    Hydraulic static transmission
    Hydraulic (high speed / low speed)
    2/2
    Transmission gears
    (2F/2R)
    Gradeability
    30%
    Traction force
    80kN
    Hydraulic oil tank capacity
    300L
    Fuel tank capacity
    200L
    Engine
    Model
    DF cumis QSB3.9-C125-30
    Rated power
    93kW/2200r/min
    Torque
    480 Nm/1350r/min
    Fuel
    (Diesel)
    Emission standard
    National 3
    Cooling
    Water cooled
    Hydraulic
    system
    Pressure
    28 MPa
    flow
    300L/min
    Steering
    system
    Steering gear type
    load sensing full hydraulic steering
    Pressure
    16 MPa
    Rear axle steering type
    Transverse hydraulic cylinder steering structure
    Steering angle
    40°





    FAQ


    Q1. What is the delivery period ?
    After receiving the initial payment, the goods will be ready for delivery within 30 days. The rest time depends on the distance and transport method which need to be negotiated.

    Q2. What is the payment terms can you accept ?
    30% initial payment, 70% balance payment when the goods are ready for delivery by T/T.

    Q3. How long is the product guarantee or warranty ?
    We provide 18 months quality guarantee, and lifelong technical support.
